Equipment for unloading cement 60-150 t/hour

A representative of the Swedish company "Scandinavian & UK Machines AB" (Sumab) invites you to learn about equipment for the production of concrete and concrete products: mobile and stationary concrete plants, vibratory presses for the production of paving slabs and curbs, equipment for the production of precast concrete wall panels and blocks, equipment for unloading and storing cement, and cold mix asphalt plants.

Sumab offers high-quality equipment at factory prices, without intermediaries.
The company provides a full range of services, including delivery, commissioning, and maintenance.

Pneumatic equipment for unloading cement from hopper cars.

Pneumatic cement transport system, capacity 60 tons/hour - 150 tons/hour (depending on equipment option).

It consists of:

- 50 m³ hopper, 4 mm sp. - 2 vibrators, 200 kg each.

- 2 augers, 323 mm in diameter, with 3000 mm extractors under the hopper.

- Vibrating mesh frame (20 x 20 mm) above the hopper with an independent vibrator.

- 8 loading chambers with compression.

- Portable tank;

- Air supply system complete with piping and guides for a maximum distance of 100 meters.

- Control cabin with PLC control panel.

Compressor not included.

Drybatch 70 S. M. rechargeable dust extractor with a recovery auger and dust extraction hood.

Euro Drybatch F 70 filter with the following technical specifications:

Filtration surface area: 70 m³.

11 kW (15 hp) centrifugal "silent" fan.

72 filter elements arranged in three rows.

Filter cleaning system with compressed air supplied in a counter-current flow, pressure from 5 to 6 bar.

5.5 dm³ compressed air tank with drainage system for condensate.

- Dust extraction hood located at the loading point, made of 360 mm³ Fe steel.

- Cement auger for recovery.

- DPM (Differential Pressure Meter) system for monitoring filter cleaning levels.

- Three-sided cover made of anti-slip plates, galvanized and painted.

- Integral discharge hopper cover. Made of steel structures, galvanized and painted on the outside, complete with a drain.

Price depends on configuration. Available upon request.

Thanks to the use of Scandinavian technology, our equipment boasts high durability and reliability.
Equipment delivery is always on time.
Over 20 years of reliable partnership.
Sumab plants operate in Europe, Ukraine, Kazakhstan, South America, the Arab States, and Africa.

Over the course of our operations, the company has delivered over 500 concrete plants of various configurations and capacities, as well as other types of equipment.
To receive a commercial offer, please send a request to our email address.
